单节锂电保护IC

单节锂电保护IC型号工作电压工作电流过充电压过充释放电流过放电压过放释放电压过放自恢复过流保护短路保护封装替代型号 DW01KA1.5-10V4.0uA4.3V4.1V2.4V3.0VOKOKOKSOT-26DW01+/CS213/R5426/R5421/SC451DW01B1.5-10V2uA4.3V4.1V2.5V2.9VOKOKOKSOT-26DW01+/CS213/R5426/R5421

型号：单节锂电保护IC

在线询价

单节锂电保护IC

型号	工作电压	工作电流	过充电压	过充释放电流	过放电压	过放释放电压	过放自恢复	过流保护	短路保护	封装	替代型号
DW01KA	1.5-10V	4.0uA	4.3V	4.1V	2.4V	3.0V	OK	OK	OK	SOT-26	DW01+/CS213/R5426 /R5421/SC451
DW01B	1.5-10V	2uA	4.3V	4.1V	2.5V	2.9V	OK	OK	OK	SOT-26	DW01+/CS213/R5426 /R5421/SC451
DW01E	2.0-10V	4uA	4.4V	4.1V	2.8V	3.0V	OK	OK	OK	SOT-26	4.35V锂电池保护应用
HM5410G	1.5-10V	3uA	4.28V	4.08V	2.5V	3.0V	NG	OK	OK	SOT-26	DW01+/CS213/R5426 /R5421/SC451
HM5410H	1.5-10V	3uA	4.28V	4.08V	2.5V	3.0V	OK	OK	OK	SOT-26	DW01+/CS213/ R5426/R5421/SC451
HM5411G	1.5-8V	3uA	4.28V	4.08V	2.9V	3.0V	OK	OK	OK	SOT-26	S8261-G3J/J3J/ FS312/R5402
HM5411H	1.5-8V	3uA	4.28V	4.08V	2.9V	3.0V	OK	OK	OK	SOT-26	S8261-G3J/J3J /FS312/R5402
HM5411K	1.5-8V	3uA	4.28V	4.08V	2.4V	2.5V	OK	OK	OK	SOT-26	S8261-G3J/J3J/ FS312/R5402
HM5412A/B/C	1.5-8V	3uA	3.75V	3.6V	2.1V	2.3V	OK	OK	OK	SOT-26	4.35V 锂电池保护应用

HM5413NA	1.5-8V	3uA	4.38V	4.28V	2.6V	2.8V	NG	OK	OK	SOT-26	4.35V锂电池保护应用
HM5413NB	1.5-8V	3uA	4.38V	4.28V	2.6V	2.8V	OK	OK	OK	SOT-26	4.35V锂电池保护应用
HM5413G	1.5-8V	3uA	4.28V	4.08V	3.0V	3.0V	OK	OK	OK	SOT-26	S8261-G3J/J3J/ FS312/R5402
HM5413J	1.5-8V	3uA	4.275V	4.075V	3.0V	2.8V	OK	OK	OK	SOT-26	S8261-G3J/J3J/ FS312/R5402
HM5413MA	1.5-8V	3uA	4.28V	4.28V	2.8V	2.8V	NG	OK	OK	SOT-26
HM5413MB	1.5-8V	3uA	4.28V	4.28V	2.8V	2.8V	OK	OK	OK	SOT-26
HM5416B	1.5-8V	3uA	4.35V	4.15V	2.5V	3.0V	OK	OK	OK	SOT-26	4.35V锂电池保护应用
HM5416D	1.5-8V	3uA	4.275V	4.175V	3.0V	3.2V	OK	OK	OK	SOT-26	S8261-G3J/J3J/ FS312/R5402
HM5416H	1.5-8V	3uA	4.420V	4.235V	2.5V	2.7V	OK	OK	OK	SOT-26	4.35V锂电池保护应用
HM8261	1.5-8V	3.5uA	4.28V	4.1V	3.0V	3.0V	OK	OK	OK	SOT-26	S8261-G3J/J3J/ FS312/R5402

DW01A/SOT-26的优点：

1.带自恢复功能
2.可以对0V电池充电
